Send from factory in 3-7 work days after receive payment
YANTE
YT-CTM
China
100% Advance T/T
Wooden Box
0~1mm thickness of paper, cardboard
0~1mm thickness of glass fiber, film, circuit board, copper foil, cable, etc.
● Using high closed loop stepping motor, the rotation angle and folding speed are accurate and stable
● ARM processor improves the corresponding speed of the instrument, and calculates the data accurately and quickly
● Automatic measurement, statistics, and printing of test results, and has the function of data storage
● Standard RS232 interface, with computer software for communication (purchased separately)
GB/T 457，QB/T1049，ISO 5626，ISO 2493
No. | Accessory name | Model | Picture | Standard | Optional |
1 | Standard Distance Cutter | YT-Q15 | | √ | |
2 | Punch Standard Distance Cutter | YT-CQ15 |
| √ | |
3 | Adjustable Paper Cutter | YT-TJD300 |
| √ |
No. | Parameter item | Technical index |
1 | Power Supply | AC(100～240)V，(50/60)Hz 100W |
2 | Working Environment | Temperature(10~35)℃, Humidity≤ 85％ |
3 | Display | 5 inch color touch screen |
4 | Measuring range | 0-99999times |
5 | Fold radius | 0.38±0.02 mm |
6 | Folding angle | （135±2）° |
7 | Spring tension | 4.91/9.81/14.72 N |
8 | Folding head gap | （0.25/0.50/0.75/1.00）mm |
9 | Built-in thermal printer | |
10 | Built-in thermal printer | RS232(Default) (USB, WIFI optional) |
11 | Dimension | 360×255×500 mm |
12 | Net Weight | 17kg around |
High Accurancy Color Analyzer is a precision instrument for measuring the whiteness, color and color difference of solids. It is widely used in papermaking, printing, textile printing and dyeing, ceramics, building materials, chemical, food, salt and other industries industries that need to determine the color and whiteness of solids in Production and commodity inspection department.
The Automatic Smoothness Tester is an intelligent paper and cardboard smoothness performance testing instrument developed based on the working principle of Bekk smoothness tester. It is an ideal testing equipment for papermaking, packaging, printing, commodity inspection, scientific research and other departments.
The Friction Coefficient Tester is used to measure the static and dynamic friction coefficients of plastic films and sheets. It can intuitively understand the smoothness and opening of the film, and display the distribution of the slip agent through a curve.
This instrument adopts a unique horizontal design. It is a new type of instrument researched and developed by our company in accordance with the requirements of the latest national standards. It is mainly used in papermaking, plastic film, chemical fiber, aluminum foil production and other industries that need to determine the tensile strength of objects. And commodity inspection department.
