Send from factory in 3-7 work days after receive payment
YANTE
YT-H4E
China
100% Advance T/T
Wooden Box
● One-click test, easy to understand
● ARM processor improves the response speed of the instrument, and the calculation is accurate and fast
● The rising and falling speed of the probe can be adjusted
● Sudden power failure data storage function, data before power failure after power-on is retained and testing can be continued.
● Automatic measurement, statistics, and printing of test results
● Communication with computer software (purchased separately)
GB/T 451.3，QB/T 1055，GB/T 24328.2，ISO 534，GB/T 6672
No. | Parameter item | Technical index |
1 | Power Supply | AC(100～240)V，(50/60)Hz 50W |
2 | Working Environment | Temperature(10~35)℃, Humidity≤ 85％ |
3 | Display | 7 inch color touch screen |
4 | Measuring range | (0～2)mm |
5 | Resolution | 0.0001mm |
6 | Indication error | ±1um |
7 | Indication variability | ±1um |
8 | Contact area | 50 mm² |
9 | Contact pressure | (17.5±1)kPa |
10 | Probe descending speed | （0.5～10）mm/s Adjustable |
11 | Built-in thermal printer | |
12 | Communication Interface | RS232(Default) (USB, WIFI optional) |
13 | Dimension | 365×255×440 mm |
14 | Net Weight | 27kg around |
Vertical Tensile Tester is used in papermaking, plastic film, chemical fiber, aluminum foil production and other industries and other production and commodity inspection departments that need to determine the tensile strength of objects.
Vertical Tensile Tester is a new type of instrument researched and developed by our company in accordance with the requirements of the latest national standards. It is mainly used in papermaking, plastic film, chemical fiber, aluminum foil production and other industries and other production and commodity inspection departments that need to determine the tensile strength of objects.
The Film Puncture Resistance Tester is an instrument developed by our company to measure the puncture strength of plastic films and sheets. The instrument has stable test data and easy operation. It is an ideal testing tool for thin film manufacturers and technical supervision departments.
The Friction Coefficient Tester is used to measure the static and dynamic friction coefficients of plastic films and sheets. It can intuitively understand the smoothness and opening of the film, and display the distribution of the slip agent through a curve.
