Send from factory in 3-7 work days after receive payment
YANTE
YT-YS05KN
China
100% Advance T/T
Wooden Box
● The ARM processor and 24-bit high-speed analog-to-digital converter improve the response speed and sampling accuracy of the instrument.
● Closed-loop servo stepping motor, ball screw, dual optical axis guide, stable operation and precise positioning.
● The 7-inch color touch screen displays the force-displacement curve in real time.
● Sudden power failure data storage function, data before power failure after power-on is retained and testing can be continued.
● Features of automatic reset, data memory, overload protection and fault self-diagnosis.
● Cooperate with computer software for communication (purchased separately).
GB/T 2679.8-1995，GB/T 4857.4，GB/T 4857.3，BB/T 0032-2006
No. | Parameter item | Technical index |
1 | Power Supply | AC(100～240)V，(50/60)Hz 100W |
2 | Working Environment | Temperature(10~35)℃, Humidity≤ 85％ |
3 | Display | 7 inch color touch screen |
4 | Measuring range | 5N～5kN |
5 | Indication accuracy | ±1％(Range 5%～100%) |
6 | Measured Area | 300×300 mm |
7 | Work Capacity | 5～300 mm |
8 | Parallelism Between Plates | ≤0.5mm |
9 | Press Speed | 50mm/min（1～500mm/min adjustable） |
10 | Return Speed | 1～500 mm/min adjustable |
11 | Built-in thermal printer | |
12 | Communication Interface | RS232(Default) (USB, WIFI optional) |
13 | Dimension | 600×425×840 mm |
14 | Net Weight | 62.5kg |
Paper Cup Stiffness Tester is a special instrument for testing the stiffness of paper cups. It is a necessary physical performance testing instrument for paper cup manufacturers, food companies and quality inspection departments.
Paper Protection Corner Tester is a testing instrument used to measure the cross direction compressive strength and machine direction strength of paper corner guards. It is an ideal testing equipment for paper corner guard manufacturers, quality inspection agencies and other departments.
Paper Bowl Compression Tester is a testing instrument for measuring the compressive strength of paper bowls. It is an ideal testing equipment for paper bowl manufacturers, quality inspection agencies and other departments.
