YT-H10E Probador Electrónico de Grosor para Papel Higiénico
El Probador Electrónico de Grosor para Papel Higiénico se utiliza para la determinación del grosor del papel higiénico.
Casa > Centro de productos > Equipo de detección de productos sanitarios > Detalles
Equipos de detección de papel y pulpa
Equipos de prueba de cartón corrugado y cartón
Equipo de detección de impresión
Equipo de detección de productos sanitarios
Equipo de detección de tejidos no tejidos
Equipo de detección de películas
Equipo de detección de polvo
Cuchillos y accesorios
Equipo de detección de productos de papel
Send from factory in 3-7 work days after receive payment
YANTE
YT-RRY1000
China
100% Advance T/T
Wooden Box
Toilet paper, tobacco sheet, fiber fabric, non-woven fabric, cloth, film, etc.
● One-click test, easy to understand
● ARM processor improves the response speed of the instrument, and calculates data accurately and quickly
● Real-time display of pressure curve
● Sudden power failure data saving function, the data before the power failure is retained after the power is turned on and the test can be continued
● Software and hardware over-range to ensure the safety of the sensor
● Communication with computer software (purchase separately)
GB/T8942,QB/T1060
No. | Parameter item | Technical index |
1 | Power Supply | AC(100~240)V,(50/60)Hz 50W |
2 | Working Environment | Temperature(10~35)℃, Humidity≤ 85% |
3 | Display | 7 inch color touch screen |
4 | Measuring range | (10~1000)mN |
5 | Indication Resolution | 0.1mN |
6 | Indication error | ±1%(Range 5%~100%) |
7 | Total probe stroke | (12±0.5)mm (Process adjustable) |
8 | Probe indentation depth | 8mm |
9 | test speed | 1.2±0.012mm/s (72±0.72 mm/min) (1-250 mm/min adjustable) |
10 | Specimen table gap width | 5/6.35/10/20mm (Four gears adjustable) |
11 | Slit parallelism error | ≤0.05mm |
12 | Probe centering error | ≤0.05mm |
13 | Built-in thermal printer | |
14 | Communication Interface | RS232(Default) (USB, WIFI optional) |
15 | Dimension | 425×290×305 mm |
16 | Net Weight | 20kg |
El Probador Electrónico de Grosor para Papel Higiénico se utiliza para la determinación del grosor del papel higiénico.
The Tissue Powder Drop Rate Tester is a basic instrument for measuring the powder drop rate of toilet paper and its products. Fix the long end of the sample on the sample holder and stop after swinging for a certain period of time, and weigh the mass before and after the swing.
This instrument adopts a unique horizontal design. It is a new type of instrument researched and developed by our company in accordance with the requirements of the latest national standards. It is mainly used in papermaking, plastic film, chemical fiber, aluminum foil production and other industries that need to determine the tensile strength of objects. And commodity inspection department.
El Probador de Reventamiento por Bola utiliza el principio de que una cabeza de prueba tipo bola perfora la muestra para analizar la resistencia a la rotura de muestras secas y húmedas.
