Send from factory in 3-7 work days after receive payment
YANTE
YT-NPY5600Q
China
100% Advance T/T
Wooden Box
Corrugated cardboard, cartons, paper trays, aluminum foil, film, rubber, silk, cotton and other non-paper materials
● The oil cylinder is driven by a stepping motor, the speed is stable, and the instrument can be used in a wide voltage range
● Pneumatic clamping system, one key test
● ARM processor, 24-bit ADC high-precision analog-to-digital converter, fast response speed, accurate measurement data
● Using 7-inch color touch screen,English display, touch buttons, real-time display of pressure curve
● Sudden power failure data storage function, data before power failure after power-on is retained and testing can be continued.
● Over-range automatic reset
● Three units can be selected kPa, kgf/cm2, Psi, can be switched at will
● Communication with computer software (purchase separately)
GB/T 1539，QB/T 2679.8，GB/T 6545，ISO 2759
No. | Accessory name | Model | Picture | Standard | Optional |
1 | Diaphragm for Board | | √ | ||
2 | Dimethicone | 201-50CS |
| √ |
No. | Parameter item | Technical index |
1 | Power Supply | AC100V±10% or AC220V±10%，(50/60)Hz，150W |
2 | Working Environment | Temperature(10~35)℃, Humidity≤ 85％ |
3 | Measuring range | 250～5600kPa |
4 | Indication error | ±0.5%(Range 5%～100%) |
5 | Resolution | 1kPa |
6 | Refueling speed | 170±15ml/min |
7 | Air pressure adjustment | 0.4MPa |
8 | Hydraulic system tightness | Upper limit of measurement，1min Pressure drop＜10％Pmax |
9 | Upper clamp ring aperture | 31.5±0.05 mm |
10 | Lower clamp ring aperture | 31.5±0.05 mm |
11 | Built-in thermal printer | |
12 | Communication Interface | RS232(Default) (USB, WIFI optional) |
13 | Dimension | 470×320×520 mm |
14 | Net Weight | 56kg around |
Bending Stiffness Tester is a multi-functional intelligent computerized stiffness tester, which calculates the test results intelligently and is widely used in papermaking enterprises, packaging manufacturers, quality inspection agencies and other units.
This instrument is a corrugated cardboard bending stiffness testing instrument designed and developed by our company according to the four-point loading method, which is suitable for all kinds of corrugated cardboard and cardboard. The higher bending stiffness makes the cardboard have a certain degree of rigidity and strength, and improves the ability of the carton to resist bulging, so as to improve the degree of protection of the contents.
Crush Tester is an ideal auxiliary test tool for papermaking companies, cardboard manufacturers, carton manufacturers, carton users, and quality supervision and inspection departments.
YT-H4E Electronic Thickness Tester is a special instrument for measuring the thickness of cardboard. It is widely used in the thickness measurement of cardboard and other sheet materials and corrugated cardboard. It is an ideal test equipment for industries and departments such as papermaking, packaging, scientific research and product quality supervision and inspection.
