Send from factory in 3-7 work days after receive payment
YANTE
YT-OPF
China
100% Advance T/T
Wooden Box
● The transmission mechanism adopts a ball screw and three guide shafts, and the transmission is stable and accurate.
● Using closed-loop servo stepping motor, low noise and precise control.
● A 7-inch color LCD touch screen is used to display the stretching curve in real time.
● The ARM processor improves the response speed of the instrument and ensures the real-time performance of the measurement.
● Sudden power failure data storage function, data before power failure after power-on is retained and testing can be continued.
● Features of automatic reset, data memory, overload protection and fault self-diagnosis.
● Cooperate with computer software for communication (purchased separately).
No. | Parameter item | Technical index |
1 | Power Supply | AC(100～240)V，(50/60)Hz 100W |
2 | Working Environment | Temperature(10~35)℃, Humidity≤ 85％ |
3 | Measuring range | (1～300)N |
4 | Indication Resolution | 0.1N |
5 | Indication error | ±1%(Range 5%～100%) |
6 | Work stroke | 500mm |
7 | Stretching speed | (1～500)mm/min(Can be adjusted arbitrarily) |
8 | Built-in thermal printer | |
9 | Communication Interface | RS232 (default) (USB, WIFI optional) |
10 | Dimension | 400×320×990 mm |
11 | Net Weight | 37kg around |
Bending Stiffness Tester is a multi-functional intelligent computerized stiffness tester, which calculates the test results intelligently and is widely used in papermaking enterprises, packaging manufacturers, quality inspection agencies and other units.
Bursting Tester for Corrugated is manufactured according to the internationally universal Mullen principle. It is a basic instrument for testing the breaking strength of cardboard; simple operation, reliable performance, and advanced technology; it is a scientific research unit, paper manufacturer, packaging industry, and quality inspection department Indispensable ideal equipment.
This instrument is a corrugated cardboard bending stiffness testing instrument designed and developed by our company according to the four-point loading method, which is suitable for all kinds of corrugated cardboard and cardboard. The higher bending stiffness makes the cardboard have a certain degree of rigidity and strength, and improves the ability of the carton to resist bulging, so as to improve the degree of protection of the contents.
Crush Tester is an ideal auxiliary test tool for papermaking companies, cardboard manufacturers, carton manufacturers, carton users, and quality supervision and inspection departments.
