Home > Product Center > Hygiene Products Testing Equipment > Details
Send from factory in 3-7 work days after receive payment
YANTE
XT-48B
China
100% Advance T/T
Wooden Box
Paper, cardboard, plastic, pulp, salt, industrial salt； Starch, calcium carbonate, talcum powder and other powders.
● Measure D65 brightness (R457 blue light whiteness)
● Measure the degree of fluorescent whitening produced by the emission of fluorescent substances (the sample contains fluorescent whitening agent)
● Measure opacity OP (customized), light scattering coefficient S, light absorption coefficient A, transparency (customized), ink absorption value
● Measure the brightness stimulus value Y10, which is the green diffuse reflection factor Ry
● Measure optical density-lead core concentration (customized small caliber)
● Advanced circuit design effectively guarantees the accuracy and stability of the measurement data
● The instrument has a power-off protection function, and the calibration data will not be lost after power-off
● This instrument is equipped with standard RS232 interface, which can be used with PC software for communication (optional)
GB/T 7973，GB/T 7974，GB/T 2679，GB/T 1543，GB/T 10339，GB/T 12911，GB/T 2913
GB/T 13025.2，GB/T 22427.6，ISO 2469，ISO 2470，ISO 2471，ISO 9416
NO. | Name | Model | Picture | Standard | Optional |
1 | Flating Powder Holder | YT-QY | | √ | |
2 | Fiber Sample Holder | | √ |
No. | Parameter item | Technical index |
1 | Power Supply | AC(100～240)V，(50/60)Hz，50W |
2 | Working Environment | Temperature(10~35)℃, Humidity≤ 85％ |
3 | Display | 128X32dot matrix LCD screen |
4 | Light source | Analog D65 |
5 | Integrating sphere | Diameter 150mm |
6 | Sample Size | Test plate diameter ≥φ30mm while sample thickness≤40mm |
7 | Zero Drift | ≤0.1 |
8 | Indicating Drift | ≤0.5 |
9 | Repetitive Accuracy | ≤0.1（10 consecutive tests at intervals of 10 seconds） |
10 | Specular Reflectance Accuracy | ≤0.1 |
11 | Communication Interface | RS232（optional） |
12 | Dimension | 370×260×425 mm |
13 | Net Weight | 12kg around |
Tissue Paper Electronic Thickness Tester is a special instrument for measuring the thickness of paper and paperboard. It is widely used for measuring the thickness of toilet paper and other sheet materials and corrugated paperboard. It is an ideal testing equipment for papermaking, packaging, scientific research, product quality supervision and inspection industries and departments.
The Tissue Powder Drop Rate Tester is a basic instrument for measuring the powder drop rate of toilet paper and its products. Fix the long end of the sample on the sample holder and stop after swinging for a certain period of time, and weigh the mass before and after the swing.
This instrument adopts a unique horizontal design. It is a new type of instrument researched and developed by our company in accordance with the requirements of the latest national standards. It is mainly used in papermaking, plastic film, chemical fiber, aluminum foil production and other industries that need to determine the tensile strength of objects. And commodity inspection department.
Ball Burst Tester uses the principle of puncturing the sample with a spherical test head to analyze the burst strength of dry and wet samples.
