Send from factory in 3-7 work days after receive payment
YANTE
YT-L
China
100% Advance T/T
Wooden Box
● Paper, cardboard; aluminum foil, aluminum-plastic tape;
● Plastic film and other non-metallic materials.
● Non-woven fabric
● Measure tensile and tensile strength
● Measuring elongation, breaking length, tensile energy absorption, tensile index, tensile energy absorption index, elastic modulus
● Measure the peel strength of adhesive tape
● The transmission mechanism adopts a ball screw and three guide shafts, and the transmission is stable and accurate.
● Using closed-loop servo stepping motor, low noise and precise control.
● A 7-inch color LCD touch screen is used to display the stretching curve in real time.
● The ARM processor improves the response speed of the instrument and ensures the real-time performance of the measurement.
● Sudden power failure data storage function, data before power failure after power-on is retained and testing can be continued.
● Features of automatic reset, data memory, overload protection and fault self-diagnosis.
● Cooperate with computer software for communication (purchased separately).
GB/T 12914，GB/T 2792，GB/T 24218.3，GB/T 1040，TAPPI T 494
No. | Accessory name | Model | Picture | Standard | Optional |
1 | Standard Distance Cutter | YT-Q15 | | √ | |
2 | Punch Standard Distance Cutter | YT-CQ15 | | √ | |
3 | Adjustable Paper Cutter | YT-TJD300 |
| √ |
No. | Parameter item | Technical index |
1 | Power Supply | AC(100～240)V，(50/60)Hz 100W |
2 | Working Environment | Temperature(10~35)℃, Humidity≤ 85％ |
3 | Display | 7 inch color touch screen |
4 | Measuring range | (0.15～30)N /(1～300)N /(3～1000)N |
5 | Display resolution | 0.01N(L30) / 0.1N(L300) / 0.1N(L1000) |
6 | Indication error | ±1%(Range 5%～100%) |
7 | Work stroke | 500mm |
8 | Sample width | 15mm(25mm，50mm Optional) |
9 | Stretching speed | (1～500)mm/min(Can be adjusted arbitrarily) |
10 | Built-in thermal printer | |
11 | Communication Interface | RS232(Default) (USB, WIFI optional) |
12 | Dimension | 400×320×990 mm |
13 | Net Weight | 40kg around |
High Accurancy Color Analyzer is a precision instrument for measuring the whiteness, color and color difference of solids. It is widely used in papermaking, printing, textile printing and dyeing, ceramics, building materials, chemical, food, salt and other industries industries that need to determine the color and whiteness of solids in Production and commodity inspection department.
The Automatic Smoothness Tester is an intelligent paper and cardboard smoothness performance testing instrument developed based on the working principle of Bekk smoothness tester. It is an ideal testing equipment for papermaking, packaging, printing, commodity inspection, scientific research and other departments.
The Friction Coefficient Tester is used to measure the static and dynamic friction coefficients of plastic films and sheets. It can intuitively understand the smoothness and opening of the film, and display the distribution of the slip agent through a curve.
This instrument adopts a unique horizontal design. It is a new type of instrument researched and developed by our company in accordance with the requirements of the latest national standards. It is mainly used in papermaking, plastic film, chemical fiber, aluminum foil production and other industries that need to determine the tensile strength of objects. And commodity inspection department.
